Leave spotting in the dark with the new professional standard in 100% spotless chip on board LED tape. Perfect for a highly desired seamless, spotless and continuous linear lighting solution. Designed for intricate projects and installation into micro width LED channels with an internal width of 4mm or more. Comes with a 500mm 2 core cable with tinned ends fitted at each of the tape and cut points every 16.67mm.

Perfect for creating eyecatching, professional, energy efficient and intricate linear lighting displays, outputting 79 Lumens per watt and 715 lumens per metre on average. Compatible with DMX, standard and professional Single Colour LED controllers.

Complete with a piece of mind 3 Year Guarantee for indoor use.
Complete with a 3m self adhesive backing for easy mounting into LED Channel.

Dimming Compatibility
Compatible with dimmers using standard control protocols including DMX, Dali, 0-10V, PWM.
Compatible with smarthome dimmers including those from Lutron, Loxone, Rayco, Control 4, Lightwave, Wizz, Casambi, Crestron.

Specifications
Ambient Operating Temperature: -20 to 60 °C (-4 to 140 °F)
Certifications/Compliance: CE, UL Listed
CRI: 90+
Colour: Warm White (3000K)
Current Consumption Max: 0.42A/m
Dimmable: Yes
Dimmer Type: PWM
Environmental Rating: Non-weatherproof, Suitable for Dry Locations
Finish: White
Input Connection Type: Pigtail
IP Rating: IP20
LED Beam Angle: 140°
LED Density: 146 LEDs/ft
LED Chip Type: COB (chip-on-board)
Length: 16.4 ft (5 m)
LED Lifetime: 50000 Hours
Minimum Cut Length: 10mm (0.39in)
Operating Voltage: 24 VDC
Product Dimensions: 196.85″ x 0.31″ x 0.08″
Strip Width: 8mm (0.31in)
Wattage: 38 Watts
Wire Gauge: 22 AWG
Wire Length: 19 in.

Photometric & Light Data
